Thermal Camera For Home Inspections
PT650 is a cutting-edge thermal camera for home inspections tool, it is for professionals seeking exceptional thermal imaging clarity in a portable, high-performance design. Featuring a 640×512 IR resolution sensor, this thermal camera for home inspections excels in capturing detailed thermal data for a wide range of applications. Whether it’s mechanical diagnostics, building inspections, electrical and home troubleshooting, this advanced thermal camera provides highly accurate results with remarkable image sharpness. The camera’s A/M-Focus system offers both manual and automatic focus options, ensuring quick and precise adjustments for perfect image clarity at every inspection point. With super resolution capabilities of the thermal camera for home inspections camera can be upgraded to 1280×1024, offering superior image quality to meet your most demanding thermal analysis needs.
Stay ahead of the curve with integrated NFC One-touch transmission ,OTA updates, and 5G communication, providing seamless data sharing and updates for faster, more efficient workflows.
Perfect for a variety of industries, the thermal camera will brings next-level precision and performance in a portable, easy-to-use design.
Features:
- Infrared Resolution:640×512 @ 12μm (Upgrade to 1280×1024)
- Frame Rate: 30Hz/9Hz for smooth imaging
- Focal Length: 17mm
- Field of View: 25°×19°
- NFC One-touch transmission
- Min. Object Distance: 0.3m for versatile close-up inspections
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
MIFusion+ Multi-spectral Image Fusion Technology
MIFusion+ adds visible light details to thermal images in real time for greater clarity and observing efficiency.
-672.jpg)
IR-Perfclear Super-resolution Reconstruction Technology
In the IR-Perfclear mode, the PT Series aims to acquire enhanced high-resolution images with better visual effects, a fourfold increase in the resolution.
.jpg)
NFC transmission, Faster than you may imagine
The NFC offers one-touch data sharing between the PT Series and another device.
.jpg)
Ultimate configuration and features, Having everything users expect
APPLICATIONS
1. Mechanical & electrical
2. Building& HVAC Inspection
3. Smart Manufacturing
4. Electrical
5. Petro Chemical
6. Scientific Research
SPECIFICATION-PT650
| Imaging and optics | |
| Detector type | VOx, 7.5 to 14μm |
| Infrared resolution | 640×512@12μm |
| Super resolution | Yes, Upgrade to 2560×2048 |
| NETD | 30mK |
| Frame rate | 30Hz/9Hz |
| Focal length | 17mm |
| Field of view | 25°×19° |
| IFOV | 0.71mrad |
| Min. object distance | 0.3m |
| D:S | 1408:1 |
| Focusing mode | Manual / Automatic / Touch autofocus / Continuous autofocus |
| Digital zoom | 1.1x to 40x |
| Measurement and analysis | |
| Measurement range | Support auto-switching: -40°C to 150°C, 0°C to 800°C, Optional 400°C to 2500°C (High temperature lens is required) |
| Measurement accuracy | ±1°C or ±1%, whichever is greater |
| Analyzed target | 30 in total (Spot/Line/Area) |
| Alarm | Full screen temperature threshold alarm (image, voice and flash) |
| Parameter settings | Emissivity, reflected temperature, target distance, humidity, atmospheric temperature, optical transmittance, dew point |
| Others | Customized physical button, Intelligent diagnosis, NFC connection, OTA update |
| Image display | |
| Display screen | 5’’ LCD, touch screen, 1920×1080 |
| Eyepiece | OLED screen, 1920×1080 |
| Image mode | IR, VIS, MIF, PIP |
| Color palettes | 15: White Hot, Iron Red, Arctic, Rainbow 2, Hot Iron, Rainbow 1, Fulgurite, Medical, Tint, Black Hot, Blue Hot, Sepia, Green Hot, Ice and Fire, Amber; Customized |
| Image adjustment | Level span mode: Automatic, Semi-automatic, Manual |
| Digital camera | Dual visible light, up to 13MP |
| Functions | |
| Laser | Laser (Indication, Ranging 0.1m to 35m) |
| Recording function | Photo (image stitching) and Video (infrared & visible light) |
| Cloud Services | Available |
| Storage and transmission | |
| Storage media | Built-in (64 GB) and external SD card (128 GB and up to 256 GB) |
| Image storage | JPG with temp info |
| Video storage | MP4 format (without temp info) can be used to record audio synchronously; Irgd (with temp info), up to 20 Hz (optional) for temperature analysis |
| External interface | Type-C, DC (12V) , SD card slot, Micro HDMI, UNC ¼”-20 (Tripod mounting) |
| WIFI | Yes, it can be connected to the mobile terminal for image and real-time video transmission |
| Cellular network | 5G module (optional) |
| Bluetooth | Bluetooth 5.0, support image transmission (only for Android) |
| Power system | |
| Battery type | Lithium-ion rechargeable battery |
| Operating time | 4 hours |
| Charging mode | The device can be charged through desktop charger after shutdown. |
| Charging time | 90% of full charge in 2.5 hours, revealed by the status screen |
| Environmental parameters | |
| Working temperature | -20°C to 50°C |
| IP rating | IP54 |
| Certification | CE, FCC, RoHS, KCC, Anatel, Damp heat test, Vibration test, Shock test, Impact test, UN38.3, MSDS |
| Physical parameters | |
| Hardware | Illuminator, Microphone, Speaker, Electronic Compass, GPS, Status screen |
| Weight | 1.86kg (with battery) |
| Size | 191×171×118mm |
| Software kit | PC: ThermoTools; Mobile: Thermography (iOS/Android) |
| Standard | A device (with lens), Lens front and back cover, Lithium-ion battery (2 pcs), Desktop charger, Power adapter, Adapter plug (5 pcs) , TYPE-C USB cable, Micro HDMI cable, Type C to GE cable, SD card (128 GB) , Wrist strap, Shoulder strap, Carrying case, Safety box, Packaging list, Quick Start Guide, Data download card (analysis software & user manual), Certificate of approval, Factory certificate |
| Options | Battery, optional lens (45°, 15°, 7°, high-temperature lens, macro lens), Carrying bag, Tripod, Bluetooth earphone, 5G module |
